Description	Performance
Switching capacity	256 Gbps
Stacking bandwidth	480 Gbps
Total number of MAC addresses	32,000
Total number of IPv4 routes (ARP plus learned routes)	32,000 (24,000 direct routes and 8000 indirect routes)
IPv4 routing entries	32,000
IPv6 routing entries	16,000
Multicast routing scale	8000
QoS scale entries	5120
ACL scale entries	5120
Packet buffer per SKU	16 MB buffer
FNF entries	64,000 flow
DRAM	8 GB
Flash	16 GB
VLAN IDs	4094
Total Switched Virtual Interfaces (SVIs)	1000
Jumbo frames	9198 bytes
Total routed ports per 9300 Series stack	448
Wireless
Forwarding rate	190.48 Mpps
Dimensions, Weight, and Mean Time Between Failures Metrics
Dimensions (H x W x D)	1.73 x 17.5 x 19.2 inch / 4.4 x 44.5 x 48.8 cm
Weight	17.03 Pounds / 7.72 Kilograms
Mean time between failures (hours)	227,410
Power Supply
Default AC power supply	1100W AC
Available PoE power	822W
Cisco StackPower	Yes
Safety and Compliance Information
Safety certifications	- UL 60950-1 - CAN/CSA-C222.2 No. 60950-1 - EN 60950-1 - IEC 60950-1 - AS/NZS 60950.1 - IEEE 802.3
Electromagnetic emissions certifications	- 47 CFR Part 15 - CISPR22 Class A - EN 300 386 V1.6.1 - EN 55022 Class A - EN 55032 Class A - CISPR 32 Class A - EN61000-3-2 - EN61000-3-3 - ICES-003 Class A - TCVN 7189 Class A - V-3 Class A - CISPR24 - EN 300 386 - EN55024 - TCVN 7317 - V-2/2015.04 - V-3/2015.04 - CNS13438 - KN32 - KN35 Additional Certifications for C9300L SKUs: - QCVN 118:2018/BTTTT - VCCI-CISPR 32 Class A
Environmental	Reduction of Hazardous Substances (ROHS) 5

Product Code	C9300-48U-E
Product Description	Catalyst 9300 48-port UPOE, Network Essentials
Total 10/100/1000 or Multigigabit copper ports	48 Cisco UPOE
Default AC power supply	1100W AC
Available PoE power	822W
Dimensions (H x W x D)	1.73 x 17.5 x 17.5 Inches
Weight	16.33 Pounds

Product number	Description
C9300-NM-4G	9300 Series 4x 1G Network Module
C9300-NM-4G=	Catalyst 9300 4 x 1GE Network Module, spare
C9300-NM-8X	9300 Series 8x 10G Network Module
C9300-NM-8X=	Catalyst 9300 8 x 10GE Network Module, spare
C9300-NM-2Q	9300 Series 2x 40G Network Module
C9300-NM-2Q=	Catalyst 9300 2 x 40GE Network Module, spare
C9300-NM-4M	9300 Series 4x Multigigabit Network Module
C9300-NM-4M=	Catalyst 9300 4 x MGig Network Module, spare
